From left to right: ChemE PhD candidate Jaesuk (Jay) Paeng stands next to Professor Gisele Azimi (ChemE, MSE) and holds the team’s newly designed electrochemical cell that can withstand temperatures up to 1600 degrees Celsius while electrochemically removing contaminants from steel using slag-based electrolyte. (photo by Safa Jinje)

University of Toronto engineering researchers have developed a new way to recycle steel that has the potential to decarbonise a range of manufacturing industries and promote a circular steel economy.

The method is outlined in a new paper published in Resources, Conservation & Recycling and co-authored by Jaesuk (Jay) Paeng, William Judge and Professor Gisele Azimi.

It introduces an innovative oxysulfide electrolyte for electrorefining, an alternative way of removing copper and carbon impurities from molten steel. The process also generates liquid iron and sulphur as by-products.

Currently, only 25% of steel produced comes from recycled material. But the global demand for a greener steel is projected to grow over the next two decades as governments around the world endeavour to achieve net-zero emission goals.

Steel Creation

Steel is created by reacting iron ore with coke — a prepared form of coal — as the source of carbon and blowing oxygen through the metal produced. Current standard processes generate nearly two tonnes of carbon dioxide per tonne of steel produced, making steel production one of the highest contributors to carbon emissions in the manufacturing sector.

Traditional steel recycling methods use an electric arc furnace to melt down scrap metal. Since it is difficult to physically separate copper material from scrap before melting, the element is also present in the recycled steel products.

The Problem with Secondary Steel Production

"The main problem with secondary steel production is that the scrap being recycled may be contaminated with other elements, including copper," says Azimi.

"The concentration of copper adds up as you add more scrap metals to be recycled, and when it goes above 0.1 weight percentage (wt%) in the final steel product, it will be detrimental to the properties of steel."

Copper cannot be removed from molten steel scrap using the traditional electric arc furnace steelmaking practice, so this limits the secondary steel market to producing lower-quality steel products, such as reinforcing bars used in the construction industry.

Their Method

"Our method can expand the secondary steel market into different industries. “It has the potential to be used to create higher-grade products such as galvanized cold rolled coil used in the automotive sector, or steel sheets for deep drawing, used in the transport sector," says Paeng.

To remove copper from iron to below 0.1 wt%, the team had to first design an electrochemical cell that could withstand temperatures up to 1600 degrees Celsius.

Inside the cell, electricity flows between the negative electrode (cathode) and the positive electrode (anode) through a novel oxysulfide electrolyte designed from slag — a waste derived from steelmaking that often ends up in cement or landfills.

"We put our contaminated iron that has the copper impurity as the anode of the electrochemical cell. We then apply an electromotive force, which is the voltage, with a power supply and we force the copper to react with the electrolyte." says Azimi.

"The electrolyte targets the removal of copper from the iron when we apply electricity to the cell," adds Paeng.

"When we apply electricity on the one side of the cell, we force the copper to react with the electrolyte and come out from iron. At the other end of the cell, we simultaneously produce new iron."

Azimi's lab collaborated with Tenova Goodfellow Inc., a global supplier of advanced technologies, products and services for metal and mining industries. Looking forward, the team wants to enable the electro-refining process to remove other contaminants from steel, including tin.

"Iron and steel are the most widely used metals in the industry, and I think the production rate is as high as 1.9 billion tonnes per year," says Azimi.

"Our method has great potential to offer the steelmaking industry a practical and easily implementable way to recycle steel to produce more of the demand for high-grade steel globally." 
